Description
Highlights
- 4-channel car amplifier
- 150 watts RMS x 4 at 4 ohms (200 watts RMS x 4 at 2 ohms)
- 400 watts RMS x 2 bridged at 4 ohms (4-ohm stable in bridged mode)
- CEA-2006 compliant
- Full-range Class D amp technology
- Ch 1 and 2: variable high-pass filter (50-4000 Hz, 12dB/octave)
- Ch 3 and 4: variable high-pass and low-pass filters (50-4000 Hz, 12dB/octave)
- Ch 3 and 4: bandpass filter option (uses low-pass and high-pass settings) and stereo/mono switch
Features
- Frequency response: 5-25,000 Hz
- Preamp and speaker-level inputs
- High-level inputs require speaker wire to RCA adapters
- Auto signal-detection and turn-on with high-level input
- Remote subwoofer level control with LED clip light included
- Fuse rating: 25A x 2
- 8-gauge power and ground leads recommended — wiring and hardware not included with amplifier
- Dimensions: 10-1/16″W x 2″H x 8″D
- Warranty: 1 year
| Amplifier Class | D |
| Low-Pass Crossover Frequency | 50 – 4000 Hz |
| Low-Pass Slope | 12 dB / octave |
| High-Pass Crossover Frequency | 50 – 4000 Hz |
| Fuse Rating | 50 |
| Preamp Output | No |
| Height | 10 ¹⁄₁₆” |
| Width | 2″ |
| Depth | 8″ |
Specifications
| RMS Power Output (Watts x Channels) | 150 x 4 |
| Power at 2 Ohms (Watts x Channels) | 200 x 4 |
| Bridged Power (Watts x Channels) | 400 x 2 |
| Minimum Impedance Bridged | 4 Ohms |
| Minimum Impedance Unbridged | 2 Ohms |
| Minimum Impedance | 2 Ohms |
| Best Frequency Response | 2 – 25k Hz |
| THD at Rated RMS Power | 1% |
| Signal to Noise Ratio | 90 dB |
| Input Voltage | 14.4 v |
