Description
Highlights
- 6-channel car amplifier
- 75 watts RMS x 6 at 4 ohms (100 watts RMS x 6 at 2 ohms)
- 200 watts RMS x 3 bridged at 4 ohms
- Class D amplifier design with NexD2™ switching amp technology
Digital Signal Processing
- 24-bit 96 kHz digital processing
- DSP adjustments and settings made with JL Audio’s TüN app (PC and Mac) via USB, via Bluetooth (tablets and phones) with BTC Bluetooth option
- 3 Project Levels of tuning: Basic, Advanced, Expert
- Input routing and mixing
- Adjustable gain controls with clip indication
- Fully adjustable high-pass, low-pass, and bandpass filters
- Selectable filter slopes (6, 12, 18, 24, 30, 36, 42, 48 dB/octave)
- 10-band EQ (graphic in Basic, parametric in Advanced and Expert modes)
- Phase and polarity control
- Time alignment in 0.01 ms increments
Connections Features
- Differential-balanced inputs eliminate noise coming from your vehicle’s electrical system
- Preamp and speaker-level inputs (speaker wire to RCA adapter required for speaker-level input)
- High-level inputs — up to 16 volts RMS (about 60 watts)
- DC offset or signal sensing auto turn-on eliminates need for remote lead
- 2-channel digital input and output (S/PDIF: up to 24-bit 192 kHz in, 24-bit 96 kHz out)
- 2-channel analog preamp output (4V RMS)
- JLid™ connections for optional Network Hub, Bluetooth Communicator, and Digital Remote Control
- USB connection for device running TüN app (6-foot cable included)
- Wiring, fuse, and hardware not included with amplifier
- 4-gauge power and ground leads and a 50-amp fuse recommended
Specifications
| RMS Power Output | 75 x 6 |
| Power at 2 Ohms | 100 x 6 |
| Bridged Power | 200 x 3 |
| Minimum Impedance Bridged | 4 |
| Minimum Impedance Unbridged | 2 |
| Minimum Impedance | 2 |
| Best Frequency Response | 12-24k Hz |
| Signal to Noise Ratio | 80 dB |
| Input Voltage | 14.4 v |
| Amplifier Class | D |
