Description
Highlights
- Mono amplifier
- 550 watts RMS x 1 at 4 ohms (850 watts RMS x 1 at 2 ohms)
- CEA-2006 compliant
- Full-range Class D amp technology
- Variable high-pass filter (10-4,000 Hz, 24 dB/octave)
- Variable low-pass filter (40-350 Hz, 24 dB/octave)
- Variable bass boost (0-6 dB at 40 Hz)
- Variable phase control (0-180 degrees)
Features
- Frequency response: 5-25,000 Hz
- Preamp inputs and outputs
- Speaker-level inputs (require speaker wire to RCA adapters)
- Auto signal-detection & turn-on with high-level input
- Wired remote level control with LED clip light included
- Fuse rating: 25A x 2
- 8-gauge power and ground leads recommended — wiring and hardware not included with amplifier
- Dimensions: 10-1/16″W x 2″H x 8″D
- Warranty: 1 year
| Amplifier Class |
D |
| Low-Pass Crossover Frequency |
40 – 350 Hz |
| Low-Pass Slope |
24 dB / octave |
| High-Pass Crossover Frequency |
10 – 4000 Hz |
| High-Pass Slope |
24 dB / octave |
| Bass Boost |
0-6 dB |
| Bass Boost Frequency |
40 Hz |
| Fuse Rating |
50 |
| Preamp Outputs |
2 |
Specifications
| RMS Power Output (Watts x Channels) |
550 x 1 |
| Power at 2 Ohms (Watts x Channels) |
850 x 1 |
| Minimum Impedance Unbridged |
2 Ohms |
| Best Frequency Response |
5 – 25k Hz |
| THD at Rated RMS Power |
1% |
| Signal to Noise Ratio |
95 dB |
| Input Voltage |
14.4v |
