Description
Highlights
- 2-channel marine amplifier
- 300 watts RMS CEA-2006 x 2 at 4 ohms (600 watts RMS x 2 at 2 ohms)
- Non-bridgeable
- Class D amp technology
- Gain knob also functions as clip light
- Variable high-pass filter (10-500 Hz, 24 dB/octave)
- Variable low-pass filter (40-5000 Hz, 24 dB/octave)
- Bandpass engages both high- and low-pass filters
- Variable bass boost (0-6 dB at 40 Hz)
Features
- Weather-resistant conformal-coated circuit boards
- Front-mounted controls protected behind gasket-sealed fold-down door
- Fail-Safe Integration Technology eliminates noise from your electrical system
- Preamp and speaker-level inputs
- Preamp outputs
- Wiring and hardware not included with amplifier
- 1/0-gauge power and ground leads and a 150-amp fuse recommended
- For multiple amplifiers, an additional 150-amp in-line fuse between the distribution block and this amplifier is recommended
- Dimensions: 11-3/16″W x 2-1/4″H x 8-3/8″D
- Warranty: 2 years
| Amplifier Class |
D |
| Low-Pass Crossover Frequency |
40Hz – 5000Hz |
| Low-Pass Slope (dB/octave) |
24dB/octave |
| High-Pass Crossover Frequency |
10Hz – 500Hz |
| High-Pass Slope (dB/octave) |
24dB/octave |
| Bass Boost |
0-6dB |
| Bass Boost Frequency |
40Hz |
| Fan Cooled |
No |
| Fuse Rating |
150 |
| Speaker Level Inputs |
Yes |
| Preamp Outputs |
1 pair |
| Height (inches) |
2-1/4 |
| Width (inches) |
11-1/4 |
| Depth (inches) |
8-7/16 |
| Parts Warranty |
2 Years |
| Labor Warranty |
2 Years |
Specifications
| RMS Power Output (Watts x Channels) |
300 x 2 |
| Frequency Response at Rated RMS Power |
20Hz-20k Hz |
| THD at Rated RMS Power |
1% |
| Signal to Noise Ratio |
95 dB |
| Input Voltage |
14.4v |
| Power at 2 Ohms (Watts x Channels) |
600 x 2 |
| Minimum Impedance Unbridged |
2 |
