Description
Highlights
- Field-Replaceable Recone Kit – cone/voice coil/spider assembly, and no gluing required
- Forced Air Cooling™
- Three-inch, aluminum voice coil former
- Dual-spider suspension
- Double-pressed pulp cone
- Heavy-duty UV-resistant Santoprene surround
- Custom rubber magnet boot
- Cast-aluminum basket
- Single 8 AWG terminal and dual 8 AWG terminal block
- Triple-Stacked Ferrite Magnet
Specifications
| Size | 10″, 25 cm |
| Rated Impedance (Ohms) | 2 DVC |
| Rec Amp Power RMS | 1000-2000 |
| Frequency Response | 25-100 |
| Magnet Diameter [in, cm] | 8-11/16,22 |
| Total Magnet Weight (oz, kg) | 406, 11.5 |
| Voice Coil Diameter (in, mm) | 3, 75 |
| Voice Winding Width (in, mm) | 2.5, 62.5 |
| Top Plate Thickness (in, mm) | 0.5, 13 |
| Xmax (in, mm) | 1.25, 31.25 |
| Mounting Cutout (in, cm) | 9-5/16, 23.7 |
| Mounting Depth (in, cm) | 9-7/16, 24 |
| Recommended Vented Box Volune (Cu. ft, L) | 2, 56.6 |
| Port Opening (in x in, cm x cm) | 2.5 x 12.25, 6 x 31 |
| Port Length (in, cm) | 38.5, 98 |
| Vented Enclosure Tuning Frequency | 31 Hz |
| Warranty: | 2 Years |
