Description
Highlights
- 4-channel powersports/marine amplifier
- 50 watts RMS x 4 at 4 ohms
- 75 watts RMS x 4 at 2 ohms
- 150 watts RMS x 2 bridged at 4 ohms
- Class D amp technology
- Variable high- and low-pass filters (50-200 Hz, 12 dB/octave)
- Variable bass boost on B channels (0-18 dB at 40 Hz)
Features
- Conformal-coated circuit boards — suitable for powersports and marine applications
- Preamp and speaker-level inputs
- Wiring and hardware not included with amplifier
- 8-gauge power and ground leads recommended
- Fuse rating: 20A x 2
- 8-7/16″W x 2-1/8″H x 6″D
- Warranty: 2 years
| RMS Power Output (Watts x Channels) |
50 x 4 |
| Frequency Response at Rated RMS Power |
20-20k Hz |
| THD at Rated RMS Power |
1% |
| Signal to Noise Ratio |
85 dB |
| Input Voltage |
14.4v |
| Peak Power Output (Watts x Channels) |
150 x 4 |
| Power at 2 Ohms (Watts x Channels) |
75 x 4 |
| Bridged Power (Watts x Channels) |
150 x 2 |
| Minimum Impedance Bridged |
4 |
| Minimum Impedance Unbridged |
2 |
|
Specifications
| Amplifier Class |
D |
| Low-Pass Crossover Frequency |
50-200 Hz |
| Low-Pass Slope (dB/octave) |
12 dB/octave |
| High-Pass Crossover Frequency |
50-200 Hz |
| High-Pass Slope (dB/octave) |
12 dB/octave |
| Bass Boost |
0-18 dB |
| Bass Boost Frequency |
40 Hz |
| Fan Cooled |
No |
| Fuse Rating |
40 |
| Speaker Level Inputs |
Yes |
| Preamp Outputs |
No |
| Height (inches) |
2-1/8 |
| Width (inches) |
8-7/16 |
| Depth (inches) |
6 |
| Parts Warranty |
2 Years |
| Labor Warranty |
2 Years |
Measurements
| Weight |
3.09 (lbs) |
| Width |
7.9 (in.) |
| Length |
10.3 (in.) |
| Height |
3.6 (in.) |
