Description
Overview
KickEQ™ delivers as much as an 6dB of extra bump with a simple turn of the knob. A powerful 24dB crossover is also included, letting you quickly tune your system to perfection. A full-range RCA output allows you to easily add another amplifier without running new signal cable to your KICKER KMC Media Center.
Highlights
- Class D Amplifier
- Gain Control With “Gain Match” LED Indicator
- FIT2™ (Fail-safe Integration Technology) Circuitry
- Variable 24dB Crossover
- DSP-Controlled Preamp
- KickEQ™ 6dB Variable Bass Boost
- ABYC/NMMA-Compliant Power Terminals
- Conformal-Coated Circuit Board to resist moisture
- Easy Access to Settings behind Gasket-Sealed Cover Panel
- Black Anodized Aluminum Chassis
- Top-Mounted, Teal LED Light Pipe
- Stainless-Steel Mounting Hardware Included
This KXMA amplifier delivers as much as 125 watts into four full-range channels, or 250 watts into two sets of bridged channels. See below for more details.
Specifications
| POWER [watts/ch], 2 OHM STEREO | 200 x 4 |
| POWER [watts/ch], 4 OHM STEREO | 100 x 4 |
| POWER [watts/ch], 4 OHM BRIDGED MONO | 400 x 2 |
| DYNAMIC POWER [watts]: | 1100 |
| DIMENSIONS [in] all models 2-1/8H x 8-5/16W x ___L | 11-9/16 |
| DIMENSIONS [cm] all models 5.4H x 21.0W x ___L | 29.4 |
| FREQUENCY RESPONSE [Hz] | 10-20k, +0/-1dB |
| INPUT SENSITIVITY | High Level 250mV-10V, Low Level 125mV-5V |
| SIGNAL-TO-NOISE RATIO | >95dB, a-weighted, re: rated power |
| ACTIVE CROSSOVER | (amp 1) 24dB/octave, variable 10-5kHz w/ 10x switch, selectable high pass, low pass or off (amp 2) 24dB/octave, variable high pass 10-500Hz, variable low pass 40-5kHz w/10x switch, selectable high pass, low pass, off or band pass |
| KickEQ™ BOOST | Variable 0-6dB, centered @ 40Hz (Only on amp 2) |
| COMES WITH WIRED REMOTE | No |
| WARRANTY | 3 Years (Authorized Kicker Dealer) |
