The D is a result of Pioneer’s automotive loudspeaker engineering experience and expertise, combining advanced design techniques with highly developed manufacturing capabilities.
Following Pioneer’s OPEN & SMOOTH sound concept, the D series of automotive loud speakers provides broad and balanced frequency response with a wide sound stage and amazing fidelity for the listener.
Features
- 26mm Polyester Soft Dome Tweeter with Swivel Capability
- Aramid Fiber Interlaced Injection Molded Polypropylene (IMPP) Cone Construction
- Universal Woofer Basket Design Expands Installation Flexibility for Maximum Bass and Sound Quality
- 3500 Hz
Specifications
System
| System Type | 2-way Coaxial |
| Sound Pressure Level (Sensitivity) | 87dB (+- 1.5dB) |
| Frequency Range | 33 Hz to 42 kHz |
| Continuous Power Handling (RMS) | 110 Watts |
| Maximum Peak Power Handling | 330 Watts |
| Nominal Impedance | 4 ohms |
Woofer
| Diameter | 6″ x 9″ |
| Cone Material | Aramid Fiber Interlaced Injection Molded Polypropylene (IMPP) |
| Surround Material | Butyl Rubber |
| Magnet Material | Ferrite |
| Magnet Weight | 15.2 oz |
Tweeter
| Type | Soft Dome |
| Diameter | 26mm |
| Diaphragm Material | Polyester |
| Magnet Material | Neodymium |
| Magnet Weight | 6.4 g |
| Swivel Type | Yes |
