Description
Highlights
- Field-Replaceable Recone Kit – cone/voice coil/spider assembly, and no gluing required
- Forced Air Cooling™
- Three-inch, aluminum voice coil former
- Dual-spider suspension
- Double-pressed pulp cone
- Heavy-duty UV-resistant Santoprene surround
- Custom rubber magnet boot
- Cast-aluminum basket
- Single 8 AWG terminal and dual 8 AWG terminal block
- Triple-Stacked Ferrite Magnet
- Biggest SoloX at 18″
Specifications
8-11/16, 22
| Size | 18″, 46 cm approx |
| Rated Impedance (Ohms) | 1 DVC |
| Rec Amp Power RMS | 1000-2000 |
| Frequency Response | 18-100 |
| Magnet Diameter (in, cm) | 8-11/16, 22 |
| Total Magnet Weight (oz, kg) | 406, 11.5 |
| Voice Coil Diameter (in, mm) | 3, 75 |
| Voice Coil Winding Width (in, mm) | 2.5, 62.5 |
| Top Plate Thickness (in, mm) | 0.5, 13 |
| Xmax (in, mm) | 1.25, 31.25 |
| Recommended Vented Box Volume (ft³, L) | 7.5, 214.5 |
| Mounting Depth (in, cm) | 11-9/16, 29.3 |
| Port Opening (in x in, cm x cm) | 6.5 x 19.5, 16.5 x 49.5 |
| Port Length (in, cm) | 27.75, 70.5 |
| Vented Enclosure Tuning Frequency (Hz) | 28 |
| Warranty | 2 Years |
