Description
Highlights
- Field-Replaceable Recone Kit – cone/voice coil/spider assembly, and no gluing required
- Forced Air Cooling™
- Three-inch, aluminum voice coil former
- Dual-spider suspension
- Double-pressed pulp cone
- Heavy-duty UV-resistant Santoprene surround
- Custom rubber magnet boot
- Cast-aluminum basket
- Single 8 AWG terminal and dual 8 AWG terminal block
- Triple-Stacked Ferrite Magnet
Specifications
| Size | 15″, 38 cm |
| Rated Impedance (Ohms) | 2 DVC |
| Rec Amp Power RMS | 1000-2000 |
| Frequency Response | 20-100 |
| Magnet Diameter (in, cm) | 8-11/16, 22 |
| Total Magnet Weight (oz, kg) | 406, 11.5 |
| Voice Coil Diameter (in, mm) | 3, 75 |
| Voice Coil Winding Width (in, mm) | 2.5, 62.5 |
| Top Plate Thickness (in, mm) | 0.5, 13 |
| Xmax (in, mm) | 1.25, 31.25 |
| Mounting Cutout (in, cm) | 13-3/4, 34.9 |
| Mounting Depth (in, cm) | 11-9/16, 29.3 |
| Recommended Vented Box Volume (Cu.ft, L) | 5, 141.6 |
| Port Opening (in x in, cm x cm) | 4.25 x 16.5, 11 x 42 |
| Port Length (in, cm) | 34.75, 88 |
| Vented Enclosure Tuning Frequency (Hz) | 30 |
| Warranty | 2 Years |
