Description
Highlights
- 2-channel line output converter
- 12-volt DC output for amplifier remote turn-on
- Bare speaker wire inputs
- Accepts up to 55 watts RMS per channel
- Applies 60-ohm load to each channel to circumvent open-circuit protection
- RCA line outputs up to 8 volts RMS
- Dimensions: 1-5/8″W x 15/16″H x 2-5/8″D
- Warranty: 1 year
Features
Overview: The Kicker KISLOC2 is a 2-channel, passive converter that allows any car stereo to be connected to an amplifier or processor (sold separately). This is accomplished by “de-amplifying” the radio’s high-level speaker outputs into low-level signals that can be passed out of the built-in RCA jacks. The KISLOC2 is designed without inductors, allowing it to deliver a flat frequency response of 20Hz – 20kHz at all volume levels.
Conversion: The KISLOC2 can accept speaker-level signals up to 55 watts and has a pair of female RCA jacks that can output an audio signal up to 8V.
OEM Compatible: The Kicker KISLOC2 is compatible with most modern OEM “smart” radios that have open-circuit protection. The KISLOC2 applies a 60Ω load to the speaker input lines, allowing the factory radio to output audio uninterrupted.
Remote Output: The KISLOC2 can provide a 12VDC/100mA remote output signal, for activating outboard amps or processors, from the converted input signal using DC offset. A red LED indicator on the input side of the converter lights when DC offset is active.
