Description
Highlights
- Peak Power : 160W
- RMS Power : 40W
- Sensitivity : 87dB/ W at 1 m
- Frequency Response : 76Hz – 21,000Hz
Woofer
- Woofer Size: 5-1/4 in (130mm)
- Woofer Diaphragm: Injection PP cone
Tweeter
- Tweeter Size: 1 in (25mm)
- Tweeter Diaphragm: Soft Dome
Dimensions (without grill)
- Width: 5-3/16 in (132mm)
- Height: 5-3/16 in (132mm)
- Depth: 2-15/16 in (75mm)
- Mounting Depth: 2-3/8 in (60mm)
Specifications
| Model Name | KFC-X134 | ||
|---|---|---|---|
| System | 2way-speaker | ||
| Power Handling | KITS Spec | ||
| Peak Input Power | 160W | ||
| Maximum Input Power | 70W | ||
| Rated Power | 35W | ||
| CTA Spec (CTA-2031 Compliant) | |||
| RMS Power | 40Watts RMS | ||
| Impedance | 4Ω | ||
| Sensitivity | 87dB/ W at 1 m | ||
| Frequency Response | 76 Hz~21,000 Hz | ||
| Woofer | Diaphragm | P.P. Cone | Gray |
| Size | Oversized 130 mm | 5-1/4 inch | |
| Surround | Rubber | ||
| Basket | Steel | ||
| Magnet | Ferrite | φ80 x ｔ13 | |
| Tweeter | Diaphragm | Soft Dome | |
| Size | 25 mm | 1 inch | |
| Magnet | Nd | Up to Engineer | |
| Dimension | Woofer | ||
| with Grille | |||
| Width | 160.0 mm | 6-5/16 inch | |
| Height | 160.0 mm | 6-5/16 inch | |
| Depth | 81.5 mm | 3-3/16 inch | |
| without Grille | |||
| Width | 132.0 mm | 5-3/16 inch | |
| Height | 132.0 mm | 5-3/16 inch | |
| Depth | 74 mm | 2-15/16 inch | |
| Cut-out Diameter | 120.0 mm | 4-3/4 inch | |
| Tweeter Height | 14 mm | 9/16 inch | |
| Mounting Depth | 60.0 mm | 2-3/8 inch | |
| Accessory | Grille | 2 pcs | |
| Grille Holder | ○ | ||
| Punching Net | ○ | ||
| Network | |||
| Tweeter | with Woofer Frame | -6dB/oct | |
| Screw sets | |||
| Binding Head Tapping Screw | φ4 x 25 mm | 8 pcs | |
| Speed Nut | φ4 | 8 pcs | |
| Speaker Cord | 0.3 m | 1 set | |
| Adhesive Tape | ○ | 1 set | |
Measurements
| Weight | 4.189 (lbs) |
| Width | 12.5 (in.) |
| Length | 7.2 (in.) |
| Height | 4 (in.) |
