Description
Highlights
- 2-way 4″ speakers (pair)
- Dual fiberglass structure woofer cone with butyl rubber surround
- Rotating aluminum inverted-dome tweeter
- Non-resonant ABS/fiberglass basket
- Wire mesh grilles included
Features
Cone Material: The Dual Fiberglass Structure Membrane (DFS) is a light, rigid, woven glass fiber woofer cone. The butyl rubber surround is resistant to ultraviolet rays, temperature extremes, and humidity to add to the speaker’s reliability and longevity.
Basket: The woofer features a fiberglass reinforced ABS basket.
Voice Coil: The voice coil is wound around a 1″ diameter low-mass Kapton former, ensuring no coil deformation.
Inverted Dome Tweeter: The tweeter is an inverted aluminum dome, producing a broad sound stage. The tweeter is angled and rotates on its post, so it can be pointed toward the listener.
| Speaker Size | 4″ |
| Design | 2-Way |
| Tweeter Design | Inverted Dome |
| Impedance | 4 Ohms |
| Tweeter Composition | Aluminum |
| Woofer Composition | DFS |
| Woofer Surround | Butyl Rubber |
Specifications
| Sensitivity (1W at 1 meter) | 83.5 |
| Sensitivity at 2.83 volts | 87.2 |
| Frequency Response | 70 – 20k Hz |
| Minimum RMS Wattage | 2 |
| Maximum RMS Wattage | 40 |
| Peak Power Handling (Watts) | 80 |
| Top-mount Depth | 2 ¹⁄₁₆” |
| Bottom-mount Depth | 2 ¼” |
| Cutout Diameter | 3 ¾” |
| Mounting Height | 0.736″ |
