Description
The Escort Redline 360c is the latest addition to the Escort family of high-performance radar detectors. Radar Detector for Tesla Model 3, Y, S, X, and Cybertruck.
- EXTREME RANGE
Relax, with extreme range (2X longer range compared to Redline EX), you’ll know exactly what’s ahead, behind and all around you - ALWAYS TRUE. NEVER FALSE
Exceptional accuracy against false alerts (AI-assisted filtering) means you’ll know what’s a real threat and what’s not* - INCREASE YOUR ROAD IQ
A powerful processor (25X more vs. Redline EX) provides rapid response times and alerts faster than ever before - SEE, BUT DON’T BE SEEN
Advanced stealth (invisible to all RDD – Radar Detector Detectors) technology ensures you stay completely anonymous - WELCOME TO THE RED ZONE
True 360° directional awareness and location accuracy within 2.5 meters give you an all-around protective shield - READY WHEN YOU ARE
A driver network with over 100 million real-time shared community alerts per year ensures maximum protection
* Based on leveraging features such as GPS AutoLearn, updatable IVT Filter, and the connected network of ESCORT drivers
WHAT’S IN THE BOX
Included with your ESCORT Redline 360c is a premium travel case, SmartCord USB charger with AutoMute, and new EZ MAG Mount.
- Quickstart Guide (pdf)
- Instruction Manual (pdf)
- Highlight Specs (pdf)
TRIPLE-ANTENNA DESIGN
Dual front, single rear antennas provide 2X the range vs previous models.
DIRECTIONAL ALERT ARROWS
Arrows indicate the direction of the radar source for 360° protection.
TOTALSHIELD™ TECHNOLOGY
Proprietary true stealth design allows usage without being detected.
AUTOLEARN TECHNOLOGY
Intelligent GPS-based technology learns routes and rejects false alerts.
CONNECTED CAR COMPATIBLE
Built-in Wi-Fi allows for instant shared alerts and software updates.
DEFENDER DATABASE
Get advanced alerts to red light camera and speed camera locations.
25X MORE PROCESSING POWER: Blackfin DSP chip provides 25X more processing power.
2.5 METERS: TELIT GPS enables location accuracy within 2.5 meters.
100% STEALTH: Patented technology allows for complete stealth.
Technical Specifications
Item # 0100040-1
REDLINE 360c TECH SPECS
OPERATING BANDS
- X-band 10.525 GHz ± 25 MHz
- K-band 24.100 GHz ± 150 MHz
- Ka-band 34.700 GHz ± 1300 MHz
- Laser 904nm, 33 MHz Bandwidth
RADAR RECEIVER / DETECTOR TYPE
- Dual Front, Single Rear Antenna with Three LNAs
- (X band – front only; K, Ka and Laser – front and rear)
- Superheterodyne, Synthesized Varactor-Tuned VCO
- Software Defined Radio Receiver (SDR)
- Blackfin DSP processor
PATENTED TOTALSHIELD TECHNOLOGY
LASER DETECTION
- Quantum Limited Video Receiver
- Multiple Laser Sensor Diodes
- SENSITIVITY CONTROL
- Highway, Auto, Auto No X and Auto Lo K
DISPLAY TYPE
- Graphic Multi-Color OLED
- Bar Graph
- 5 Levels of Brightness with Full Dark Mode
MUTE, AUTOMUTE AND SMARTMUTE
POWER REQUIREMENT
- 12VDC, Negative Ground
- SmartCord USB Included
BLUETOOTH SMART (BLE)
WI-FI 802.11 B/G (2.4 GHz)
UNIT DIMENSIONS
- 1.3” H x 3.35” W x 5.13” D
USER PREFERENCES
- User Mode: Advanced / Novice
- Pilot: Scanning Bar / Full Word
- Arrow Mode: Single / Multiple / Band
- Display Color: Blue/Green/Red/Amber
- Speed Display: On / Off
- Cruise Alert: Off / 20 – 160 mph
- Over Speed: Off / 20 – 160 mph
- Over Speed Limit: Off / Spd Limit / 5 over / 10 over / 15 over / 20 over
- Meter Mode: Standard/FR1/FR2/Spec/Expert/Simple
- Tones: Standard / Standard+ / Mild
- AutoMute: Low / Med / High / Off
- AutoLearn: On / Off
- Units: English / Metric
- Language: English / Spanish
- Voice: On / Off
- GPS Filter: On / Off
- Auto Power: Off / 1-8 Hours
- Bands: X/K/KN1-KN4/Ka/KaN1-KaN10/Ka-POP/Laser/TSR
- Markers: Other/RedLight/RedLight & Speed Cam/Speed Cam/Speed Trap/Air Patrol
- Clear Locations: Marked/Lockouts/Defender/Format
- Wi-Fi: On / Off
- Bluetooth: On / Off
- Auto Update: Off/Database/Firmware/All
- Perform Update: Firmware/Database
